| Power |
:5kw |
| Supply Voltage |
: 230vAV / Single Phase / 50Hz |
| Air Supply |
: 5-6 Bar at 120 las/min |
| Working Stroke |
: 350mm |
| Heater Head Movement |
: Motorized Jogging / Return Stroke Automatic |
| Average Heating Time |
: 20secs |
| Possible Tool Diameters |
: 3 mm to 32mm |
| User Interface |
: Via 4” Monochrome Touch Screen |
| Cooling |
: Using Compressed Air |
| Cooling Method |
: In line with Heating Coil |
| Cooling Time |
: 2-3 mins (can be set by operator) |
| Cooling Distance |
: Can be set by operator based on tool height |
| Cooling for Tool Removal |
: Can be set-off if not required |
| Heating Chart |
: Based on tool diameters / Heating Time |
| Cooling Chart |
: Based on tool diameters / Holder Height |
